VStarcam CCTV ONVIF 1080P/720P pan tilt cmos p2p ir wifi camera indoor wireless hidden camera

FOB Reference Price:Get Latest Price
US $44-80 / Pieces | 2 Piece/Pieces ip camera sample order is acceptable (Min. Order)
Key Company Capacity
Production Capacity >
  • Employees: 301 - 500 People
  • Factory Size: 5,000-10,000 square meters
  • No. of Production Lines: Above 10
Research & Design >
  • No.of R&D Engineer: Above 50 People
  • Production Certification: 3
  • Trademark: 1
Trade Capacity >
  • Export Mode: Using an agent Have Own Export License
  • Export Percentage: 71% - 80%
  • No. of Employees inTrade Department: Above 50 People
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
VStarcam
Model Number:
C23S wireless indoor ir security camera
Type:
IP Camera
Style:
Box Camera
Sensor:
CMOS
Special Features:
Vandal-proof
Compression Format:
H.264 wireless indoor ir security camera
Lens:
3.6mm
Technology:
UID scan technology surveillance camera, NetWork
Resolution:
1080P/720P(1280X720) VGA(640X480) QVGA
WIFI setting:
one key wifi setting
ONVIF:
Support
IR-CUT:
Dural IR-CUT Filter
PT:
Pan: 270° /Tilt 70°
Multi-Platform Software:
Android,iOS,Windows
Certification:
CE, FCC,ROHS, ISO
Supply Ability
Supply Ability:
100000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
VStarcam Brand/OEM/Neutral Package wireless indoor ir security camera
Port
Shenzhen

VStarcam CCTV ONVIF 1080P/720P pan tilt cmos p2p ir wifi camera hd 1080p indoor wireless hidden camera



Product Description

View more, do more, and protect more with the clarity and mobile control of VStarcam Pan & Tilt Day/Night wireless ONVIF wireless wireless indoor ir security camera. Download the free EYE4 app and monitor your home or business – anywhere, anytime – on your smartphone or tablet. Experience confident clarity and total control with the ultra-smooth pan/tilt and two way audio functionality. Integrated motion-sensing and night-vision technology provides around-the-clock surveillance. With simple installation, you’ll have an effective, affordable home or business surveillance video camera solution up and running in no time.





Features



1. 9pcs LED, IR distance 10M. Lens 3.6 mm IP surveillance camera

2. Support ONVIF 2.0, RTSP protocol

3.  WPS one key setup WiFi, acoustic wave wifi setting

4. 1080P/720P,VGA,QVGA triple stream

5. Two-way audio, Remote Pan/Tilt rotate IP camera

6. Wi-Fi/802.11/b/g/n,support dynamic IP

7. Motion detection, email alert, FTP upload

8. Iphone, 3G phone, Smartphone supported

9. Multi-language, Firefox, Safari, Google browser

10. Pan:270 degree, Tilt: 70degree, auto cruise
11. Support 128GB TF Card





Specifications



Model No. :C23S
FeatureFeaturesSmall body size,perfect combination of hardware and software through software limit, and more stable.
SystemOSEmbedded Linux OS
system securityThree level user authority management
online userssupport 4 online visitors simultaneously
DDNSFree DDNS
Control protocolONVIF 2.0 protocol, high interoperability
ProcessorHisilicon processor,built-in ARM926 @Max. 440MHz and a high-speed video co-processor.
ResetLong press for 15 seconds to restore back to factory settings
CollectionImage sensor1/4inch 1080p/720p Progressive scan CMOS sensor
CMOSsupport AWB, AGC, BLC
sensor size3.84mm×2.16mm
SNR39dB
Minimum illumination0.8Lux/F1.4(colourful model ),0.3Lux/F1.(B&W mode)
Lens/viewing angle3.6mm @ F1.4/ 56.14 degree
Night visionDual IR-CUT filter auto switch, 9pcs 850nmΦ5mm LED,10m IR distance
IR control IR turned on: night vision view enabled, infrared Ray, ICR auto detect.                                                             IR turned off: night vision disabled, infrared ray off, ICR stay in day view mode.
VideoCompression FormatH.264 Main Profile/H.264 Baseline Profile/MJPEG/JPEG Baseline
Video coding processMulti-stream:720P/24fps+VGA/30fps+QVGA/30fps+720P @1fsJPEG snapshot
Resolution 1080P/720p/VGA/QVGA
Bit RateCBR/VBR, output bit rate range:128~4096kbps
Frame rate25fps
Picture AdjustmentContrast, brightness, saturation, chroma are adjustable.
AudioInputBuilt in -48dB Microphone
OutputBuilt in speaker(8Ω1W)
Sampling frequency / width8KHz/16bit
Compression formatADPCM/32kbps
NetworkInterface10Base-T / 100Base-TX, RJ45 connector
Network ProtocolTCP/IP,HTTP,TCP,UDP,SMTP,FTP,DHCP,DNS,DDNS,NTP,UPnP,RTSP,P2P,etc.
WIFIWiFi802.11b/g/n
Antenna3dBi antenna,stronger signal, more stable
Wireless network securityWPS one key setup WiFi
storageStorage modeLocal storage / client storage
InterfaceMicro SD
Pan-TiltP/TPan:270°,Tilt:70°
Preset Postion support up to 15 preset postions
Limit methodSoftware limit position, more accurate preset positions,lower Pan Tilt failure rate
AlarmMotion detectionSupport motion detection
Alarm actionImage upload via email/FTP server
Physical indexRated VoltageDC5/2A±0.3V
Power comsumptionRated power:3.0W(IR ON)
Working environmentWorking Temperature:-20~70℃,Working Humidity 90%
WeightGross Weight :295g (Note: in kind prevail)
Housing materialABS plastics
Camera size98x105x120mm(L×W×H)
InstallationWall mounting, ceiling mounting
 Only for reference
