Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: VStarcam
  • Model Number: C82R
  • Type: Digital Camera
  • Style: Box Camera
  • Sensor: CMOS
  • Technology: NetWork, UID scan technology IP camera
  • Special Features: Vandal-proof
  • Lens: 3.6mm
  • Resolution: 1080P(1920*1080P)720P(1280X720) VGA(640X480) QVGA
  • WIFI setting: one key wifi setting
  • ONVIF: Support
  • Compression Format: H.264
  • IR-CUT: Dural IR-CUT Filter
  • PT: Pan: 280° /Tilt 80°
  • Multi-Platform Software: Android,iOS,Windows
  • Certification: CE, FCC,ROHS, ISO

Packaging & Delivery

Packaging Details VStarcam Brand/OEM/Neutral Package
Delivery Time 3-5days

Mini hidden camera 1080p HD security p2p wifi ip camera with free uid

Product Description

View more, do more, and protect more with the clarity and mobile control of VStarcam Pan & Tilt Day/Night wireless ONVIF wireless hidden security webcam with sd card. Download the free EYE4 app and monitor your home or business – anywhere, anytime – on your smartphone or tablet. Experience confident clarity and total control with the ultra-smooth pan/tilt and two way audio functionality. Integrated motion-sensing and night-vision technology provides around-the-clock surveillance. With simple installation, you’ll have an effective, affordable home or business infrared digital camera solution up and running in no time.





1. 12pcs LED, IR distance 10M. Lens 3.6 mm

2. Support ONVIF 2.0, RTSP protocol

3.  WPS one key setup WiFi, acoustic wave wifi setting

4. 1080P,720P,VGA,QVGA triple stream

5. Two-way audio, Remote Pan/Tilt rotate

6. Wi-Fi/802.11/b/g/n,support dynamic IP

7. Motion detection, email alert, FTP upload

8. Iphone, 3G phone, Smartphone supported

9. Multi-language, Firefox, Safari, Google browser

10. Pan:270 degree, Tilt: 80degree, auto cruise
11. Support 128GB TF Card





Model No C:82R
FeaturesFeaturesSoftware limit position, lower Pan Tilt failure rate
SystemOSEmbedded Linux OS
System securityThree level user authority management
Online usersSupport 4 online visitors simultaneously
Control protocolONVIF 2.4 protocol, high interoperability
ProcessorHisilicon processor,built-in ARM926 @Max. 440MHz and a high-speed video co-processor.
ResetLong press for 15 seconds to restore back to factory settings
CollectionImage sensor1/4inch 1080p Progressive scan CMOS sensor
Imaging area4.40mm×2.52mm
Minimum illumination0.8Lux/F1.4(colourful model ),0.3Lux/F1.(B&W mode)
Lens/viewing angle3.6mm @ F1.4/56.14 degree
Night visionDual IR-CUT filter auto switch, 12pcs 850nmΦ5mm LED,10m IR distance
IR control IR turned on: night vision view enabled, infrared Ray, ICR auto detect.                                                             IR turned off: night vision disabled, infrared ray off, ICR stay in day view mode.
VideoCompression FormatH.264 Main Profile/H.264 Baseline Profile/MJPEG/JPEG Baseline
Video coding processMulti-stream:720P/24fps+VGA/30fps+QVGA/30fps+720P @1fsJPEG snapshot
Resolution 1080P/720p/VGA/QVGA
Bit RateCBR/VBR, output bit rate range:128~4096kbps
Max.Frame rate25fps
Picture AdjustmentContrast, brightness, saturation, chroma are adjustable.
AudioInputBuilt in -48dB Microphone
OutputBuilt in speaker(8Ω1W)`
Sampling frequency / width8KHz/16bit
Compression formatADPCM/32kbps
NetworkInterface10Base-T / 100Base-TX, RJ45 connector
Antenna3dBi antenna,stronger signal, more stable
Wireless network securityOne key setup WiFi
StorageStorage modeLocal storage / client storage
InterfaceMicro SD/TF
Preset Postion Support up to 15 preset postions
Limit methodSoftware limit position, more accurate preset positions,lower Pan Tilt failure rate.
AlarmMotion detectionSupport motion detection
Alarm actionVideo upload via email/FTP server,Mobile App alarm
Physical indexRated VoltageDC5/2A±0.3V
Power comsumptionRated power:3.0W(IR ON)
Working environmentWorking Temperature:-20~70℃,Working Humidity 90%
WeightGross Weight:330g (Note: in kind prevail)
Housing materialABS plastics
Camera size145 x 110 x 125 mm (L×W×H)
InstallationWall mounting, ceiling mounting




Detailed Images
