Quick Details
- Place of Origin: Guangdong, China (Mainland)
- Brand Name: VStarcam
- Model Number: E27
- Type: Digital Camera
- Style: Mini Camera
- Sensor: CMOS
- Technology: NetWork
- Special Features: IR-CUT
- Features: NetWork, PnP,P2P
- Resolution: 1280*720(720P)
- Motion detection alarm: Support
- RTSP: Support
- ONVIF: Support
- Two way audio: Support
- Pan/Tilt: Pan 335° Tilt 120°
- Local Memory: Max 64G TF Card
- Certificate: FCC CE RoHS
Packaging & Delivery
| Packaging Details | Net weight: 0.65kg, Package size:208*154*137mm (L*W*H) |
|---|---|
| Delivery Time | Shipped in 1 days after payment |
E27 SMART HOME Kits WiFi RF Zigbee battery powered wireless ip camera kits
1) High Definition, H.264 CMOS 2.0MP,
2) Support Onvif, triple stream.
3) Pan:355°,Tilt:80° ,
4) 3.6mm Lens,
5) 12pcs 5mm IR LEDS 10m IR distance,
6) Two way audio.
7 ) indoor ip camera wireless
8) P2P/WPS encryption, Easier to set up WiFi and viewing in Moblile.
9) Triple Stream 720P/ VAG
10) Support up to 128G TF card memory, 24-hour recording.
11) Built-in IR-CUT, no color no cast. 12pcs IR LEDS, 10m Night Vision
12) Built in Microphone & Speaker, 2 way audio, excellent cavity design, loud intercom.
13) Support WiFi/ DDNS. PC/APP to control multi-cameras.
14) 4-Channel view, support up to 10 online users viewing viewing on line at the same time.
15) Motion dectection, Massage alert, FTP upload
16) Wi-Fi/802.11/b/g/n,support dynamic IP
16) wireless home security
The specification of E27 KITS
Model | E27 | |
Features | l Come with universal remote control,can control devices with remote control, such as TV conditioning projector, etc. l 1080P, 720P, VGA triple stream. l Support Windows,iPhone,ipad and Android phone. l Smart phone APP remote control home appliances l ZigBee/RF/IR remote control l Built-in more than 100,000 kinds of remote control code database,and constantly updated. l 1.0M FHD,Video is very clear and smooth. l One key WiFi configuration, matching code in smart way. l Built-in microphone and speaker, two way audio. l Support up to 128G TF card storage, loop recording. | |
System | OS | Embedded Linux OS |
Online users | Support 4 online visitors simultaneously | |
DDNS | Free DDNS | |
Processor | Hi3518E chipset micro-processor | |
Collection | White Balance | Automatic adjustment |
Backlight compensation | Automatic adjustment | |
Gain control | Automatic adjustment | |
Minimum illumination | 0.1Lux(B&W mode),0.5Lux(Color mode) | |
Lens/Viewing angle | 4.0mm/67.2°(diagonal) | |
Night version | Dual IR-CUT filter auto switch,8pcs 850nmΦ5mm IR LEDs,10m IR distance | |
Compression format | H.264/MJPEG/JPEG | |
Video | Resolution | 1080P/360P/180P |
Video coding process | FHD(15fps)/VGA(15fps)/QVGA(15fps) | |
Bit rate | VBR Dynamic data rate,Bit rate range:128~4096Kbps | |
Maximum frame rate | 20fps | |
Picture adjustment | Brightness,Contrast,Saturation,hue are adjustable | |
Alarming Indicate recording | Support | |
Audio | Input | Built in-40dB Microphone |
Output | Built in Speaker (8Ω1W)` | |
Network
| RJ45 | Support |
WiFi | WiFi802.11b/g/n | |
One key WiFi configuration | Support | |
Network adapter | 10Mbps/100Mbps adaptive | |
Network protocol | TCP/IP,HTTP,TCP,UDP,SMTP,FTP,DHCP,DNS,DDNS,NTP,UPnP,P2P etc. | |
Pan-tilt | P/T | Pan:350° Tilt:97° |
Preset positions | PC: Support 16 preset positions Phone:Support 5 preset positions | |
Pan-tilt | P/T | Pan:355° Tilt:110° |
Preset positions | PC: Support 16 preset positions Phone:Support 5 preset positions | |
IR | Feature | IR learn and send,Learn:5 Control:30 |
Work frequency band | 38kHz | |
Encoding mode | Infrared carrier | |
ZIGBEE | Encoding mode | ZigBee Base on IEEE802.15.4 |
Work frequency band | 2.4GHz | |
Feature | Lower power consumption,free networking | |
Communication | Two-way communication, send and receive distance more than 100 meters | |
RF | Encoding mode | ASK 100W class encoding |
Work frequency band | 433MHz | |
Communication | Single direction communication,send and receive distance more than 80 meters | |
Storage | Storage mode | Alarm recording,Micro SD card,local storage |
Memory | Micro SD/TF card,Support up to 128GB | |
Physic Index | Working environment | Working Temperature:-10~50℃,Working Humidity <90% |
Rated Voltage | DC5V±5% | |
Power consumption | Rated power:3.0W(IR on)/ Maximum power consumption:5.0W(P/T on) | |
Housing material | ABS plastics | |
Weight | Gross Weight:1150g(Note:in kind prevail) | |
Camera size | (Kits)323x133x207mm (L×W×H) | |
Certifications | ISO \FCC\ CE\ ROHS | |
|
| (Note:in kind prevail) |
Shenzhen VStarcam Technology Co., Ltd., is a professional network camera manufacturer, with many years experience in the surveillance industry R & D, strict quality control processes, professional service for customers to create the perfect video security monitoring overall solution program. Products include infrared waterproof camera, PTZ network cameras, gun-type network camera, network dome camera, high definition network cameras, IP cameras, wireless video cameras!
Packaging & Delivery
| Packaging Detail: | VStarcam Brand or Neutral packing . OEM is accepted. Gross Weight : 0.65KG Package size: 200x179x120mm(LXWXH) |
• OEM Service: We could offer OEM and ODM services for our clients.
• Delivery Time: Sample order 3-5 working days, bulk order 7-15
working days.
• Delivery Term: ByExpress(DHL/FEDEX/TNT/UPS),By air,By Sea.
• Quality Warranty: One year warranty.
• We provide 4BS service: best quality, best price, best
delivery, best service.
• We have Sole Agents from different countries.
( Sole Agent in Korea, Russia, Spain, Ukraine, Thailand, Egypt, Canada,India, Indonesia, Pakistan, Australia, Singapore, Chile, Malaysia, Switzerland,LAOS,Myanmar, UK,Saudi Arabia, Brunei, Oman)
Good after-sales service:
---Refund within 7 days
---Replacement within 15 days
---1 Year warranty
Q1. What is the Processor use of IP camera:
==>
A1: It is Hisilicon processor
Q2: How to reset Ip camera?
==>
A2:Long press for 15 seconds to restore back to factory settings
Q3. How to storage video:
==>
A3: 1) storage mode: local storage/client storage/NVS/NVR storage
2) Card: support 128G TF card
3) Interface: TF card
Q4. How to connect IP Camera with device?
==>A4: Our private App EYE4 software downloaded on Android, IOS, Windows
Q5: is it possible to make a customization for mass order?
==>
A5: Yes, we also do OEM/ODM
* Printing silk-screen company logo on products==> The MOQ is 100pcs
* Printing laser company logo on products==> The MOQ is 100pcs
* Color gift box customized==> The MOQ is 500pcs
Q6: Can you take samples for testing first?
==>
A6: Yes, it is ok for you to take samples before mass order
Q7. What is the payment way works?
==>
A7: T/T, L/C, Paypal, Western Union
Q8: Are they waterproof?
==>
A8: Yes, our product waterproof performance is IP66
Q9. Why choose IP Cameras of VStarcam:
==>
A9: * Mainly products are private design, App EYE4 for IOS&Android&Window belong to us,
* OEM/ODM service offers
* With CE&ROHS&FCC Certificates:
* High quality goods, competitive price, the best service, fast delivery...........
